9000R Series Overview

Medallion’s 9000R Series is our most popular robust line, ideal for locations requiring the ultimate level of security and vandal resistance. This series is the Architects choice for applications such as: office complexes, hotels, condominiums, corporate headquarters, universities, hospitals, cemeteries and box store garden centres. Quality assurance utilizing Allied Flo Coat® triple coated steel or where specified, High Tensile Marine Grade Aluminum.

9000R Series Features & Specifications

undefined

ARMOUR-SHIELD™ Protection
Allied Flo Coat® Triple Coated Steel
Stainless Steel Welds
Super Durable Polyester Powder Coated
Rails: 64mm x 38mm (2-1/2" x 1-1/2")
Pickets: 38mm x 19mm (1-1/2" x 3/4")
Posts Minimum: 76mm x 76mm (3" x 3")

undefined

Alu-Tuff™ Protection
Marine Grade Aluminum
Aluminum Mig Welds
Super Durable Polyester Powder Coated
Rails: 64mm x 38mm (2-1/2" x 1-1/2")
Pickets: 38mm x 19mm (1-1/2" x 3/4")
Posts Minimum: 76mm x 76mm (3" x 3")

Medallion 9000R Series Armour-Shield™

Solid Tube Rails
Interior Weld Seam Zinc Coated
Chromate Conversion Coating
Organic Clear Coat Sealer / Primer
JS1000™ Plating on Bracket Fasteners
Super Durable Polyester Powder Coat
3000 Hours Salt Spray ASTM-B117

Other Brands

Open Channel Rails
Interior Weld Seam Left Unprotected
No inline Chromate Conversion Coating
No Organic Clear Coat Sealer / Primer
Standard Grade Plating on Fasteners
Regular Grade Polyester Powder Coat
800 – 1000 Hours Typical

Architects - Specifiers - Developers Open Access to our resource library of drawings & specifications
